SPECIFICATIONS

Brand Name: SatMaximum

Certification: NONE

FTA(Free To Air): Yes

High Definition: Yes

High-concerned chemical: None

Input Frequency: 10.7-12.75GHz

L.O Frequency: 9.75/10.6GHz

Model Number: YL-3604

Noise: 0.1dB

Origin: Mainland China

Package: Yes

Type: DIGITAL

With USB Wifi: No

Specifications

Output - Quad (4)

Low Noise 0.1dB

Low Power Consumption

Very High Frequency Stability

Very High Cross Pol Performance

Input Low Band - 10.7 - 11.7GHz

Input High Band - 11.7 - 12.75 GHZ

Output Frequency Low - 950 - 1950 MHZ

Output Frequency High - 1100 - 2150 MHZ

L.O Frequency Low - Typ 9.75 GHZ

L.O Frequency High - Typ 10.6 GHZ

Output Connector - 75ohm F-Type

Phase Noise dBc/Hz @1kHz - 60, @10kHz - 80, @100kHz - 100

Conversion Gain - 65dB

Cross-Pole Isolation - Min: 20dB, Typ: 25dB

Flatness 5dB Over Operating Band

Fitting - 40mm (Standard Size)

Weather - Waterproof Boot
